UEY1 Automatic Reset Overvoltage Protectors
- Product Series: UEY1
- Product Name: Automatic Reset Overvoltage Protectors
- Number of Poles: 1P+N、3P+N
- Rated Operating Voltage [Ue]: AC230V(1P+N)、 AC400V(3P+N)
- Rated Insulation Withstand Voltage Ui: 400V
- Rated Impulse Withstand Voltage Uimp: 4kV
Overview
The UEY1 series Automatic Reset Overvoltage Protectors features a high-speed, low-power microprocessor as its core control circuit, with a magnetic latching relay as the main circuit. It is designed with a modular standard approach.
When the power supply line experiences over-voltage or under-voltage, the protectors can quickly and safely cut off the circuit under continuous high-voltage impact, preventing abnormal voltage from being sent to the terminal electrical equipment, thus avoiding accidents.
When the voltage returns to normal, the reset overvoltage protectors will automatically reconnect the circuit within a specified time, ensuring the normal operation of the terminal electrical equipment under unattended conditions.
Product Description
Automatic Reset Overvoltage Protectors
Overvoltage Protectors features 1:
– The single-phase line is cut off when the over-voltage occurs. The single-phase line voltage returns to normal after a delay, the line is automatically reset and connected without manual operation
– When transient or transient overvoltage occurs in the line, the overvoltage protectors will not cause misoperation
Overvoltage Protectors features 2:
– When the overvoltage protectors are unstable due to the fault of the line such as false contact, or the sudden power failure and sudden call, the overvoltage protectors do not connect the line
– When the line fault voltage is the highest, the protector itself will not be damaged
Overvoltage Protectors features 3:
– The overvoltage protectors are segmented and inverse time limit, and the overvoltage and undervoltage operation time meets the standard JB/T 12762-2015
– The overvoltage protectors use leds to indicate the working status, green – power indicator, red – overvoltage indicator
Overvoltage Protectors features 4:
– Yellow – Undervoltage indicator, blinking red or yellow – Delay recovery on indicator
– Withstand impulse voltage: 4kV (in line with Class III electrical safety standards)
– Modular shape design, rail installation
Related Products
UEY1 Automatic Reset Overvoltage Protectors
Compensation Contactor Module UEC1-K series
UEW6DHG DC Disconnectors
Residual Current Circuit Breaker 2 Pole
Smart MCB
UER3 Thermal Overload Relay
Automatic Reset Overvoltage Protector Advantages
1. Compact and Durable Design: It features a compact design that is durable and can be easily installed in standard cabinet-style distribution cabinets.
2. High Current Interrupting Capacity: These protectors have a strong ability to interrupt high currents, with some models capable of handling up to 150kA.
3. Rich Maintenance Functions: The logic controller, acting as the brain of the protector, offers a variety of adjustable protection parameters, including over-load long-time delay, short-circuit short-time delay, short-circuit instantaneous, and ground fault protection.
4. Automatic Reset: After the voltage returns to normal, the protector can automatically reconnect the circuit without the need for manual operation, making it suitable for unattended environments.
5. Prevention of False Tripping: The design ensures that the protector does not falsely trip during transient or momentary over-voltages.
6. Safe Operation: It can quickly and safely disconnect the circuit under continuous high-voltage stress, preventing abnormal voltage from causing accidents in terminal electrical equipment.
7. High Surge Voltage Tolerance: The protector is capable of withstanding high surge voltages, complying with the safety standards for Class III electrical equipment.
8. Status Indication: It includes dual-color LED indicators to clearly show the working status, with green indicating normal voltage and red indicating over-voltage or under-voltage conditions or delays.
9. Modular Design: The protector has a modular design that facilitates rail mounting, enhancing installation efficiency and uniformity.
10. Wide Range of Applicability: It is suitable for a variety of voltage and frequency ranges, meeting the usage requirements of different regions and electrical equipment.
Automatic Reset Overvoltage Protectors Application Area
- Power Distribution System
- Mining Distribution System
- Metallurgy Distribution System
- Construction Distribution System
- Chemical Distribution System
- Petroleum Distribution System
- Transportation Distribution System
Automatic Reset Overvoltage Protectors Technical Specification
- Overvoltage action cut-off value: > 275Va.c (phase voltage)
- Overvoltage recovery: ≤1.1Ue (240Va.c ~ 253 Va.c)
- Undervoltage operation cut-off value: < 160Va.c (phase voltage)
- Undervoltage recovery: > 195Va.c (phase voltage)
- Delayed reset connecting time: 30s±5s
- Protection class: IP20
- Time Reset delay: 20s to 60s
Why Choose Kemus
Kemus Automatic Reset Overvoltage Protectors Production Process
– Production Capacity of Automatic Reset Overvoltage Protector: With a robust manufacturing process, we produce 80-100 batches of Automatic Reset Overvoltage Protector per month, ensuring a consistent supply to meet market demands.
– Original Country Technology: Our Automatic Reset Overvoltage Protector incorporate cutting-edge technology sourced directly from the countries of origin, guaranteeing the latest advancements in electrical safety.
– Quality Assurance: Every Automatic Reset Overvoltage Protector we manufacture has a 100% passing rate in quality checks, reflecting our commitment to excellence and reliability in every unit.
Automatic Reset Overvoltage Protectors Application Fields
Kemus Power Technology Cooperative Brand
Working with us, you will get
Kemus is a leading provider of electrical switchgear and electronic components. Our electronic products reflect our commitment to ensuring reliability and adherence to global safety standards, marked by certifications such as UL/CUL, VDE, COC, and CCC. Kemus insists on a comprehensive quality assurance system, ensuring our products meet global standards for safety and reliability.
- Direct Factory Price
- Quality Without Compromise
- Supply Stability
- Delivery On Time
- Thoughtful Service
- More Options From Us
- Useful introduction and suggestion
- Less communication, better understanding
Products Packing & Delivery
Automatic Reset Overvoltage Protectors FAQ
- What is Kemus Automatic Reset Overvoltage Protector? Automatic Reset Overvoltage Protector is a protective device in the electrical power system that can automatically disconnect the circuit in case of voltage anomalies to safeguard the connected electrical equipment from damage, and it will automatically reconnect the circuit once the voltage returns to normal.
- How does Kemus ensure the quality? Kemus Products has passed CCC, CB, TUV certification.
- Can I get samples from your company? Yes, Samples can be provided.
- If products have some quality problem, how would you deal with? Our company will responsible for all the quality problems.
- What is the customer you work with? We work with famous brands such as: Enel, SMA, JCI, GE, Honeywell, United Technologies, SGCC, Sinopec, China GuoDian, Power China, China Post, ZiJin Minning and so on.
- How long is the disconnector warranty period? Kemus Automatic Reset Overvoltage Protector warranty period is 2 years
- What is your lead time? Normal within 10 days. It depends on detail items and quantity.
