UEM5L MCCB RCD Circuit Breaker
- Product Name: MCCB RCD
- Product Model: UEM5L-100/250/400/630/800
- Poles Description: 3P（1）、4P
- Product or Component Type: Earth leakage circuit breaker
- Device Application: Distribution
- Network Type: AC
- Network Frequency: 50 Hz
- Certificates: CB/CCC/UKCA/CE
Overview
This UEM5L MCCB RCD circuit breakers has isolation function.
Circuit breakers can be equipped with undervoltage release device, shunt release device, auxiliary contact, alarm contact, electric operating mechanism, manual operating mechanism and other accessories.
Product Description
UEM5L MCCB RCD Circuit Breaker
UEM5L MCCB RCD Circuit Breaker is suitable for AC 50Hz/60Hz, rated current from 10A to 1600A, rated insulation voltage of 800V, rated working voltage of 690V and below the low-voltage power grid, with overload, short circuit and undervoltage protection function.
UEM5L MCCB RCD with residual current protection circuit breakers provide protection against dangerous voltages caused by insulation damage, and can also provide protection against hazards such as fire caused by insulation damage.
UEM5L MCCB RCD Product Characteristics
-Insulating parts such as base, cover and shaft are made of thermosetting composite materials, which have high strength and high insulation performance.
-MCCB RCD unique contact design, fast breaking speed and small tripping force.
-MCCB RCD rotating flip structure, easy to install accessories without opening cover.
-MCCB RCD adopt advanced electromagnetic repulsion technology to quickly extinguish the arc.
UEM5L MCCB RCD Certificates of Compliance
| CB |
IEC60947-2
|
| CCC |
GB/T 14048 .2
|
| UKCA | BS EN 60947-2 |
| CE | EN60947-2 |
Related Products
UEY1 Automatic Reset Overvoltage Protectors
Compensation Contactor Module UEC1-K series
UEW6DHG DC Disconnectors
Residual Current Circuit Breaker 2 Pole
Smart MCB
UER3 Thermal Overload Relay
UEM5L MCB RCD Circuit Breaker
Standard operating environment and installation conditions
Leakage Circuit Breaker Operating Temperature:
– The reference operating ambient temperature of the thermal element with the thermal magnetic overcurrent release is set to +40 ° C
– Between +40°C and +70 °C, due to the temperature characteristics of the bimetal sheet of the trip device, the thermal trip value must be reduced
– Thermal trip value can be increased when below +40°C
– The performance of the microprocessor overcurrent release does not fluctuate due to the change of temperature, but when the temperature is higher than +40°C, due to the current in the circuit breaker
– The copper parts (moving and static contacts and connection terminals) flowing through will undergo some changes that will cause the rated continuous current to be reduced, and the maximum set value of the overload protection function will need to be reduced
– The performance of the circuit breaker cannot be guaranteed when the ambient temperature is higher than +70 ° C.
-In order to ensure the continuity of the work of the power equipment, it is necessary to consider keeping the temperature at a temperature where all the equipment can work normally, rather than only considering the operating temperature of the circuit breaker, such as taking strong ventilation in necessary occasions.
Altitude:
-Above 2000 m, with the increase of altitude, the composition of the atmosphere, insulation properties, cooling properties and air pressure change. At this time, the performance of the circuit breaker will be reduced, mainly in some major parameters, such as the maximum operating voltage and rated operating current and dielectric strength.
UEM5L-250 Technical Parameter
- Device Short Name: UEM5L-250
- Product or Component Type: Earth Leakage Circuit Breaker
- Poles Description: 3P（1）、4P
- Rated Current [In]: 100A、125A、140A、160A、180A、200A、225A、250A
- Rated Operational Voltage[Ue]: 400 V AC
- Network Type: AC
- Network Frequency: 50 Hz
- Rated Insulation Voltage [Ui]: 800 V AC 50 Hz
- Rated Impulse Withstand Voltage [Uimp]: 8 kV
- Mechanical Durability: 7000 cycles
- Electrical Durability: 1000 cycles at 400 V In
- Connection Pitch: 35 mm
UEM5L-630 Technical Parameter
- Device Short Name: UEM5L-630
- Product or Component Type: Earth Leakage Circuit Breaker
- Poles Description: 3P（1）、4P
- Rated Current [In]: 400A、500A、630A
- Rated Operational Voltage[Ue]: 400 V AC
- Network Type: AC
- Network Frequency: 50 Hz
- Rated Insulation Voltage [Ui]: 800 V AC 50 Hz
- Rated Impulse Withstand Voltage [Uimp]: 8 kV
- Mechanical Durability: 4000 cycles
- Electrical Durability: 1000 cycles at 400 V In
- Connection Pitch: 44 mm
Why Choose Kemus
Kemus Company Products Superiority
– High reliability: They responsible for protecting lines and equipment in the power system, which itself has high reliability and anti-interference, and can effectively protect the normal operation of the power system.
– High flexibility: They can be adjusted and controlled according to actual needs, with high flexibility and operability, and can adapt to different power system needs.
– Easy maintenance: If an electronic component fails, it can quickly replace the failed component;
– Supply Ability: Our company spirit of “all the pursuit of high quality, customer satisfaction for the purpose”, to provide customers with the most favorable prices, the most thoughtful service and the most reliable product quality.
– Original Country Technology: Our products incorporate cutting-edge technology sourced directly from the countries of origin, guaranteeing the latest advancements in electrical safety.
– Quality Assurance: Every products our company provide has a 100% passing rate in quality checks, reflecting our commitment to excellence and reliability in every unit.
Application Fields
Kemus Power Technology Cooperative Brand
Cooperate with us, you will get
Kemus is a leading provider of electrical switchgear and electronic components. Our electronic products reflect our commitment to ensuring reliability and adherence to global safety standards, marked by certifications such as UL/CUL, VDE, COC, and CCC. Kemus insists on a comprehensive quality assurance system, ensuring our products meet global standards for safety and reliability.
- Direct Factory Price
- Quality Guaranteed
- Supply Stability
- Delivery On Time
- Thoughtful Service
- More Options From Us
- Professional introduction and advice
- Small size and weight, save space
- Modular design reduces installation difficulty
- Removable, replaceable, easy to maintain and repair
- Reduce maintenance costs and time costs
- Reduce power system losses
- High flexibility and maneuverability
- As technology advances, it is easy to upgrade
Products Packing & Delivery
AC Breaker FAQ
- What is the customer you work with? We work with famous brands such as: Enel, SMA, JCI, GE, Honeywell, United Technologies, SGCC, Sinopec, China GuoDian, Power China, China Post, ZiJin Minning and so on.
- How does Kemus ensure the quality? Kemus Products have passed CCC, CB, TUV, CQC, CE, UKCA certification.
- Can I get samples from your company? Yes, Samples can be provided.
- How long is the disconnector warranty period? Kemus AC Leakage Circuit Breaker warranty period is 18 months.
- What is your lead time? Normal within 10 days. It depends on detail items and quantity.
- If products have some quality problem, how would you deal with? Our company will responsible for all the quality problems.
