Distribution Metering Box Series DBX
- Series: DBX
- Type: Distribution Metering Box
- Application: Metering for Power Distribution
- Rated Frequency (fr): 50Hz
- Rated Voltage: 220V / 380 V
- Warranty: 18 months
Overview
Distribution Metering Box Series DBX is engineered to meet the demands of modern energy management. Operating within the AC 50Hz, 220V/380V TN-C systems, it provides a comprehensive solution for residential and commercial electricity metering. This compact unit seamlessly integrates essential electrical components, including switchgear for circuit control, precision measuring instruments for accurate energy tracking, protective electrical appliances to ensure safety, and auxiliary equipment for enhanced functionality. Its secure design not only deters unauthorized access but also guarantees reliable performance, making it an ideal choice for projects aiming to implement the “one household, one meter” policy effectively.
Product Description
1. Distribution Metering Box Series DBX Product Features:
—Main Instrument:
—Surface Coating:
Finished with a powder spray coating, allowing for customizable color selection.
—Integrated Design:
One-piece construction with a rational internal layout divided into three independent units: Inlet, Metering, and User Units, each with its own door and detachable sealing plate for enhanced enclosure.
—Safety Characteristics:
Inlet and metering unit doors have built-in locks, allowing for padlocks and lead seals, providing excellent anti-theft electricity features.
—Adjustable Metering Position:
Direct installation capability for energy meters with adjustable and secure positioning.
2.Metering Distribution Box Diagram:
3.Metering Control Box Series DBX Technical Parameters:
| Feature | Unit | Value |
| Rated Voltage | V | 220/380 |
| Rated Current | A | 10~250 |
| Rated Frequency | Hz | 50 |
| Rated Insulation Voltage | V | 400 |
| Rated Short-time Withstand Current | kV | 4.5 |
4.Distribution Metering Control Cabinet Series DBX Technical Standard:
| GB/T7251.2-2023 |
| GB/T14048 |
| IEC61439-2:2020 |
Related Products
Power Distribution Cabinet GL21
Gas Insulated Ring Main Unit HXGN-12 Series
SF6 High Voltage RMU-XGN12
Why Choose Kemus
Distribution Metering Cabinet Series DBX Receiving Inspection
Upon the arrival of Series DBX Power Distribution Panel , it’s crucial to conduct a thorough receiving inspection. Verify that the model specifications and quantities match your order. We recommend retaining the original wooden case for protection until installation.Should you encounter any issues, reach out within a 5-day window post-receipt to address any discrepancies or damages.
Working with us, you will get
Kemus as HongFa agent, Choose Kemus for DBX box and gain access to superior safety, innovation, and global compliance in electrical protection.
- Direct Factory Price
- Quality Without Compromise
- Supply Stability
- Delivery On Time
- Thoughtful Service
- More Options From Us
- Useful introduction and suggestion
- Less communication, better understanding
Packing & Delivery
Power Distribution Metering Control Box Series DBX FAQ
- 01.Can the DBX Series be customized with different colors? Yes, the surface coating is done using a powder spray process, allowing for color selection based on user needs.
- 02. How is the DBX Series metering control box structured internally? It has a one-piece construction with a rational internal layout divided into three independent units for inlet, metering, and user applications.
- 03.Does the DBX Series offer any specific security features against electricity theft? Yes, it features built-in locks on the inlet and metering unit doors, allowing for padlocks and lead seals for enhanced security.
- 04. Can the position for installing energy meters in the DBX Series be adjusted? Yes, the metering position is adjustable vertically and can be reliably fixed.
- 05. How is the DBX Series metering control box protected against environmental factors? The box is made with a PC face cover and ABS base or steel plate welding structure, which is coated with a protective layer to resist environmental wear.
- 06.What kind of maintenance is required for the DBX Series metering control box? Regular visual inspections are recommended, along with periodic checks of the internal components to ensure they are clean and functioning properly.
Kemus Metering Box Series DBX Applications
